| Max Print Size |
|
minimum 12" wide
up to 64" wide |
| Physical Dimensions |
103"(W) x 50"(D) x 52"(H)
Printer weight: 500 lbs |
| Optional Dryer |
68"(W) x 9.5"(D) x 11"(H)
Dryer weight: 20 lbs |
| Ink Type |
UltraChrome GS2 Solvent, virtually odorless printing with no special ventilation or air purification systems required |
| PRINTING COLOR MODEL |
4 COLOR 8-channel, drop-on-demand, ink jet head |
| MAX INK SIZE |
700ML |
SMALLEST DOT SIZE |
4.2 picoliters |
| HEAD TECHNOLOGY |
Advanced MicroPiezo TFP Print Head
|
| Software
|
ONYX GamaPrint Pro RIP |
| MAX RESOLUTION |
1440 x 1440 |
| DATA CONNECTION |
USB & 10/100/1000 ETHERNET |
| Heavy Roll Media System |
(OPTIONAL) enables the use of heavier media up to 175 lbs |
| High Speed Print Dryer |
(OPTIONAL) This optional high speed media dryer is only necessary in locations where the print speed and environmental conditions require faster drying times.
|
| |
|
| Electrical Requirements |
120/240 Vac, 50/60 HZ (automatic voltage selection) |
| Standard Warranty |
One-year Optional extended warranty available |
| Operating System Supported |
Client Workstation:
Macintosh® 10.5+, Windows 7, Vista or XP (32-bit or 64-bit)
Server Workstation:
Windows 7, Vista® or XP (32-bit or 64-bit)
3.2 GHz Intel® i7 or better 6 GB memory
recommended
|
|
|
| PRINT SPEED |
|
| 1440 x 720 dpi, 8-pass |
77 SF Per Hour |
| 720 x 720 dpi, 6-pass |
105 SF Per Hour |
| 720 x 720 dpi, 4-pass |
152 SF Per Hour |
| 720 x 720 dpi, 3-pass |
205 SF Per Hour |
| 720 x 720 dpi, 2-pass |
315 SF Per Hour |
720 x 360 dpi, 1-pass |
|
620 SF Per Hour |
EPSON SureColor 30670
